Micro Pump select

Customization

Customization is our standard practice: all our pumps can be modified to meet your specific requirements. And within a few days. Customized range of mini pumps:

Voltage: DC 3-24 V
Air flow: 0.5-100 L/min
Pressure: 0.5-7 bar
Vacuum: -30-95 kpa
Diaphragm Material: EPDM/PTFE/FKM

Features

# Efficient and durable design
# Smallest size and lightest weight
# Oil-free and non-contaminating media
# Maintenance free and easy to install
# Excellent air tightness
# Long life, continuous operation
# Low noise and low vibration

Applications

Small, portable
# Beauty Equipment
# Medical Equipment
# Physical therapy instruments
# Household appliances
# Testing instruments
# Gas sampling instruments
# Industrial machines
# Environmental cleaning equipment
# Automotive pressure supply
# Pressure and vacuum supply

What can you get? When you choose us!

Micro pump specialists with 15 years of experience in the pump vertical field.

ISO 9001 quality management system approved.

Micro Diaphragm Air Vacuum Pumps With Brush Motor

DC brushed motor miniature diaphragm pumps with low cost and a life span of between 500 and 1000 hours for intermittent working scenarios. The transfer medium is air or slightly corrosive gases. Conventional diaphragm and valve material is EPDM, special for material FKM. Learn more.

Model	Voltage	Current	Free Flow	Max Pressure	Max Vacuum	Motor	Dimention(LxWxH)
BD-01A	3V	0.4A	0.8 L/min	1 bar		Brush	45.5x15.5x25.5 mm
BD-01A	3V	0.6A	1 L/min	1 bar		Brush	45.5x15.5x25.5 mm
BD-01A	6V	0.2A	0.8 L/min	1 bar		Brush	45.5x15.5x25.5 mm
BD-01A	6V	0.3A	1 L/min	1 bar		Brush	45.5x15.5x25.5 mm
BD-01A	12V	0.1A	0.8 L/min	1 bar		Brush	45.5x15.5x25.5 mm
BD-01A	12V	0.15A	1 L/min	1 bar		Brush	45.5x15.5x25.5 mm
BD-01V	3V	0.4A	0.5 L/min		-30 kpa	Brush	45.5x15.5x25.5 mm
BD-01V	3V	0.6A	0.8 L/min		-50 kpa	Brush	45.5x15.5x25.5 mm
BD-01V	6V	0.2A	0.5 L/min		-30 kpa	Brush	45.5x15.5x25.5 mm
BD-01V	6V	0.3A	0.8 L/min		-50 kpa	Brush	45.5x15.5x25.5 mm
BD-01V	12V	0.1A	0.5 L/min		-30 kpa	Brush	45.5x15.5x25.5 mm
BD-01V	12V	0.15A	0.8 L/min		-50 kpa	Brush	45.5x15.5x25.5 mm
BD-02A	6V	0.2A	1 L/min	0.5 bar		Brush	55x24x40 mm
BD-02A	6V	0.4A	1.5 L/min	1 bar		Brush	55x24x40 mm
BD-02A	6V	0.4A	3 L/min	1.5 bar		Brush	55x24x40 mm
BD-02A	12V	0.1A	1 L/min	0.5 bar		Brush	55x24x40 mm
BD-02A	12V	0.2A	1.5 L/min	1 bar		Brush	55x24x40 mm
BD-02A	12V	0.2A	3 L/min	1.5 bar		Brush	55x24x40 mm
BD-02A	24V	0.1A	1 L/min	0.5 bar		Brush	55x24x40 mm
BD-02A	24V	0.1A	1.5 L/min	1 bar		Brush	55x24x40 mm
BD-02A	24V	0.1A	3 L/min	1.5 bar		Brush	55x24x40 mm
BD-02V	6V	0.2A	1 L/min		-40 kpa	Brush	55x24x40 mm
BD-02V	6V	0.4A	1.5 L/min		-50 kpa	Brush	55x24x40 mm
BD-02V	6V	0.4A	2.5 L/min		-60 kpa	Brush	55x24x40 mm
BD-02V	12V	0.1A	1 L/min		-40 kpa	Brush	55x24x40 mm
BD-02V	12V	0.2A	1.5 L/min		-50 kpa	Brush	55x24x40 mm
BD-02V	12V	0.2A	2.5 L/min		-60 kpa	Brush	55x24x40 mm
BD-02V	24V	0.1A	1 L/min		-40 kpa	Brush	55x24x40 mm
BD-02V	24V	0.1A	1.5 L/min		-50 kpa	Brush	55x24x40 mm
BD-02V	24V	0.1A	2.5 L/min		-60 kpa	Brush	55x24x40 mm
BD-03A	6V	0.8A	3 L/min	2 bar		Brush	76x30x49 mm
BD-03A	6V	0.8A	5 L/min	2.5bar		Brush	76x30x49 mm
BD-03A	6V	1.6A	6 L/min	3 bar		Brush	76x30x49 mm
BD-03A	12V	0.4A	3 L/min	2 bar		Brush	76x30x49 mm
BD-03A	12V	0.4A	5 L/min	2.5bar		Brush	76x30x49 mm
BD-03A	12V	0.8A	6 L/min	3 bar		Brush	76x30x49 mm
BD-03A	24V	0.2A	3 L/min	2 bar		Brush	76x30x49 mm
BD-03A	24V	0.2A	5 L/min	2.5bar		Brush	76x30x49 mm
BD-03A	24V	0.4A	6 L/min	3 bar		Brush	76x30x49 mm
BD-03V	6V	0.8A	3 L/min		-55 kpa	Brush	76x30x49 mm
BD-03V	6V	1.6A	4 L/min		-70 kpa	Brush	76x30x49 mm
BD-03V	12V	0.4A	6 L/min		-70 kpa	Brush	76x30x49 mm
BD-03V	12V	0.4A	3 L/min		-55 kpa	Brush	76x30x49 mm
BD-03V	12V	0.8A	4 L/min		-70 kpa	Brush	76x30x49 mm
BD-03V	24V	0.2A	6 L/min		-70 kpa	Brush	76x30x49 mm
BD-03V	24V	0.2A	3 L/min		-55 kpa	Brush	76x30x49 mm
BD-03V	24V	0.4A	4 L/min		-70 kpa	Brush	76x30x49 mm
BD-03V	24V	0.4A	6 L/min		-70 kpa	Brush	76x30x49 mm
BD-04A	6V	1.2A	9 L/min	2 bar		Brush	101x40x72 mm
BD-04A	6V	1.6A	15 L/min	2.5 bar		Brush	101x40x72 mm
BD-04A	6V	2.4A	18 L/min	3 bar		Brush	101x40x72 mm
BD-04A	12V	0.6A	9 L/min	2 bar		Brush	101x40x72 mm
BD-04A	12V	0.8A	15 L/min	2.5 bar		Brush	101x40x72 mm
BD-04A	12V	1.2A	18 L/min	3 bar		Brush	101x40x72 mm
BD-04A	24V	0.3A	9 L/min	2 bar		Brush	101x40x72 mm
BD-04A	24V	0.3A	15 L/min	2.5 bar		Brush	101x40x72 mm
BD-04A	24V	0.6A	18 L/min	3 bar		Brush	101x40x72 mm
BD-04V	6V	1.2A	10 L/min		-75 kpa	Brush	101x40x72 mm
BD-04V	6V	1.6A	15 L/min		-80 kpa	Brush	101x40x72 mm
BD-04V	6V	2.4A	18 L/min		-80 kpa	Brush	101x40x72 mm
BD-04V	12V	0.6A	10 L/min		-75 kpa	Brush	101x40x72 mm
BD-04V	12V	0.8A	15 L/min		-80 kpa	Brush	101x40x72 mm
BD-04V	12V	1.2A	18 L/min		-80 kpa	Brush	101x40x72 mm
BD-04V	24V	0.3A	10 L/min		-75 kpa	Brush	101x40x72 mm
BD-04A	24V	0.3A	15 L/min		-80 kpa	Brush	101x40x72 mm
BD-04A	24V	0.6A	18 L/min		-80 kpa	Brush	101x40x72 mm

Generated by wpDataTables

Micro Diaphragm Air Vacuum Pumps With Brushless Motor

DC brushless motor miniature diaphragm pumps with low electromagnetic interference and a life time between 3000-5000 hours, suitable for continuous duty scenarios. Standard voltage ratings available in 3V,6V,9V,12V,24V, custom voltage range 3V-30V. Learn more.

Model	Voltage	Current	Free Flow	Max Pressure	Max Vacuum	Motor	Dimention(LxWxH)
BD-02AB	6V	0.2A	1 L/min	0.5 bar		Brushless	53x24x40 mm
BD-02AB	6V	0.4A	1.5 L/min	1 bar		Brushless	53x24x40 mm
BD-02AB	6V	0.4A	3 L/min	1.5 bar		Brushless	53x24x40 mm
BD-02AB	12V	0.1A	1 L/min	0.5 bar		Brushless	53x24x40 mm
BD-02AB	12V	0.2A	1.5 L/min	1 bar		Brushless	53x24x40 mm
BD-02AB	12V	0.2A	3 L/min	1.5 bar		Brushless	53x24x40 mm
BD-02AB	24V	0.1A	1 L/min	0.5 bar		Brushless	53x24x40 mm
BD-02AB	24V	0.1A	1.5 L/min	1 bar		Brushless	53x24x40 mm
BD-02AB	24V	0.1A	3 L/min	1.5 bar		Brushless	53x24x40 mm
BD-02VB	6V	0.2A	1 L/min		-40 kpa	Brushless	53x24x40 mm
BD-02VB	6V	0.4A	1.5 L/min		-50 kpa	Brushless	53x24x40 mm
BD-02VB	6V	0.4A	2.5 L/min		-60 kpa	Brushless	53x24x40 mm
BD-02VB	12V	0.1A	1 L/min		-40 kpa	Brushless	53x24x40 mm
BD-02VB	12V	0.2A	1.5 L/min		-50 kpa	Brushless	53x24x40 mm
BD-02VB	12V	0.2A	2.5 L/min		-60 kpa	Brushless	53x24x40 mm
BD-02VB	24V	0.1A	1 L/min		-40 kpa	Brushless	53x24x40 mm
BD-02VB	24V	0.1A	1.5 L/min		-50 kpa	Brushless	53x24x40 mm
BD-02VB	24V	0.1A	2.5 L/min		-60 kpa	Brushless	53x24x40 mm
BD-03AB	6V	0.8A	3 L/min	2 bar		Brushless	64x30x49 mm
BD-03AB	6V	0.8A	5 L/min	2.5bar		Brushless	64x30x49 mm
BD-03AB	6V	1.6A	6 L/min	3 bar		Brushless	64x30x49 mm
BD-03AB	12V	0.4A	3 L/min	2 bar		Brushless	64x30x49 mm
BD-03AB	12V	0.4A	5 L/min	2.5bar		Brushless	64x30x49 mm
BD-03AB	12V	0.8A	6 L/min	3 bar		Brushless	64x30x49 mm
BD-03AB	24V	0.2A	3 L/min	2 bar		Brushless	64x30x49 mm
BD-03AB	24V	0.2A	5 L/min	2.5bar		Brushless	64x30x49 mm
BD-03AB	24V	0.4A	6 L/min	3 bar		Brushless	64x30x49 mm
BD-03VB	6V	0.8A	3 L/min		-55 kpa
BD-03VB	6V	0.8A	4 L/min		-70 kpa
BD-03VB	6V	1.6A	6 L/min		-70 kpa
BD-03VB	12V	0.4A	3 L/min		-55 kpa
BD-03VB	12V	0.4A	4 L/min		-70 kpa
BD-03VB	12V	0.8A	6 L/min		-70 kpa
BD-03VB	24V	0.2A	3 L/min		-55 kpa
BD-03VB	24V	0.2A	4 L/min		-70 kpa
BD-03VB	24V	0.4A	6 L/min		-70 kpa
BD-04AB	6V	1.2A	9 L/min	2 bar		Brushless	92x40x72 mm
BD-04AB	6V	1.6A	15 L/min	2.5 bar		Brushless	92x40x72 mm
BD-04AB	6V	2.4A	18 L/min	3 bar		Brushless	92x40x72 mm
BD-04AB	12V	0.6A	9 L/min	2 bar		Brushless	92x40x72 mm
BD-04AB	12V	0.8A	15 L/min	2.5 bar		Brushless	92x40x72 mm
BD-04AB	12V	1.2A	18 L/min	3 bar		Brushless	92x40x72 mm
BD-04AB	24V	0.3A	9 L/min	2 bar		Brushless	92x40x72 mm
BD-04AB	24V	0.3A	15 L/min	2.5 bar		Brushless	92x40x72 mm
BD-04AB	24V	0.6A	18 L/min	3 bar		Brushless	92x40x72 mm
BD-04VB	6V	1.2A	10 L/min		-75 kpa	Brushless	92x40x72 mm
BD-04VB	6V	1.6A	15 L/min		-80 kpa	Brushless	92x40x72 mm
BD-04VB	6V	2.4A	18 L/min		-80 kpa	Brushless	92x40x72 mm
BD-04VB	12V	0.6A	10 L/min		-75 kpa	Brushless	92x40x72 mm
BD-04VB	12V	0.8A	15 L/min		-80 kpa	Brushless	92x40x72 mm
BD-04VB	12V	1.2A	18 L/min		-80 kpa	Brushless	92x40x72 mm
BD-04VB	24V	0.3A	10 L/min		-75 kpa	Brushless	92x40x72 mm
BD-04A	24V	0.3A	15 L/min		-80 kpa	Brushless	92x40x72 mm
BD-04A	24V	0.6A	18 L/min		-80 kpa	Brushless	92x40x72 mm

Generated by wpDataTables

Small Piston Gas Air Vacuum Pumps With Brush Motor

12V/24V brush motor oil-free miniature piston pump, low cost for bulk purchase, life between 800-1000 hours, excellent pneumatic data, max flow rate 40L/min, max pressure 650kPa. pump head available in PPS and aluminium alloy. Learn more.

Model	Voltage	Current	Free Flow	Max Pressure	Max Vacuum	Motor	Dimention(LxWxH)
BD-07A	12V	2A	15 L/min	5 bar		Brush	108x43x87 mm
BD-07A	12V	2.5A	25 L/min	6 bar		Brush	108x43x87 mm
BD-07A	12V	4A	30 L/min	6 bar		Brush	108x43x87 mm
BD-07A	12V	4A	35 L/min	6.5 bar		Brush	108x43x87 mm
BD-07A	24V	1A	15 L/min	5 bar		Brush	108x43x87 mm
BD-07A	24V	1.5A	25 L/min	6 bar		Brush	108x43x87 mm
BD-07A	24V	2A	30 L/min	6 bar		Brush	108x43x87 mm
BD-07A	24V	2A	35 L/min	6.5 bar		Brush	108x43x87 mm
BD-07V	12V	2A	15 L/min		-85 kpa	Brush	108x43x87 mm
BD-07V	12V	2.5A	25 L/min		-85 kpa	Brush	108x43x87 mm
BD-07V	12V	4A	30 L/min		-85 kpa	Brush	108x43x87 mm
BD-07V	12V	4A	35 L/min		-86 kpa	Brush	108x43x87 mm
BD-07V	24V	1A	15 L/min		-85 kpa	Brush	108x43x87 mm
BD-07V	24V	1.5A	25 L/min		-85 kpa	Brush	108x43x87 mm
BD-07V	24V	2A	30 L/min		-85 kpa	Brush	108x43x87 mm
BD-07V	24V	2A	35 L/min		-86 kpa	Brush	108x43x87 mm

Generated by wpDataTables

Small Piston Gas Air Vacuum Pumps With Brushless Motor

DC brushless motor oil-free piston air pump, low EMI, CE and EMC approved. Life span of 3000-5000 hours, suitable for continuous working scenarios. Widely used in vacuum lifters, medical atomisation, cleaning fogging and other scenarios. Learn more.

Model	Voltage	Current	Free Flow	Max Pressure	Max Vacuum	Motor	Dimention(LxWxH)
BD-07AB	12V	2A	15 L/min	5 bar		Brushless	101x43x87 mm
BD-07AB	12V	2.5A	25 L/min	6 bar		Brushless	101x43x87 mm
BD-07AB	12V	4A	30 L/min	6 bar		Brushless	101x43x87 mm
BD-07AB	12V	4A	35 L/min	6.5 bar		Brushless	101x43x87 mm
BD-07AB	24V	1A	15 L/min	5 bar		Brushless	101x43x87 mm
BD-07AB	24V	1.5A	25 L/min	6 bar		Brushless	101x43x87 mm
BD-07AB	24V	2A	30 L/min	6 bar		Brushless	101x43x87 mm
BD-07AB	24V	2A	35 L/min	6.5 bar		Brushless	101x43x87 mm
BD-07VB	12V	2A	15 L/min		-85 kpa	Brushless	101x43x87 mm
BD-07VB	12V	2.5A	25 L/min		-85 kpa	Brushless	101x43x87 mm
BD-07VB	12V	4A	30 L/min		-85 kpa	Brushless	101x43x87 mm
BD-07VB	12V	4A	35 L/min		-86 kpa	Brushless	101x43x87 mm
BD-07VB	24V	1A	15 L/min		-85 kpa	Brushless	101x43x87 mm
BD-07VB	24V	1.5A	25 L/min		-85 kpa	Brushless	101x43x87 mm
BD-07VB	24V	2A	30 L/min		-85 kpa	Brushless	101x43x87 mm
BD-07VB	24V	2A	35 L/min		-86 kpa	Brushless	101x43x87 mm

Generated by wpDataTables

Mini Compressor air vacuum pump with brush motor

DC brush mini compressor, compact size, with inlet and outlet ports for inflation and suction. All aluminium alloy for frequent load starting, good heat resistance. Can replace large oil-free piston air pumps or compressors, new applications for home, portable, mobile, backpack. Great size and weight, its biggest selling point! Learn more.

Model	Voltage	Current	Free Flow	Max Pressure	Max Vacuum	Motor	Dimention(LxWxH)
BD-08A-S	24V	4A	40 L/min	6 bar		Brush	8853123mm
BD-08A-D	24V	4A	80 L/min	7 bar		Brush	13253123mm
BD-08V-S	24V	4A	40 L/min		-85 kpa	Brush	8853123mm
BD-08V-D	24V	4A	70 L/min		-85 kpa	Brush	13253123mm
BD-09V-1	12V	10A	40 L/min		-85 kpa	Brush	15686137
BD-09V-1	24V	5.5A	40 L/min		-85 kpa	Brush	15686137

Generated by wpDataTables

Mini Compressor air vacuum pump with brushless motor

24V powerful micro compressed air and vacuum performance. Brushless motor, 5000 hours long life, with CE and EMC certificate. Double-headed pump in parallel max. pressure 7 bar, max. flow 80 L/min. Very small size, oil-free, maintenance-free, patented technology, you won’t find a second one! Learn more.

Model	Voltage	Current	Free Flow	Max Pressure	Max Vacuum	Motor	Dimention(LxWxH)
BD-08AB-S	24V	4A	40 L/min	6 bar		Brushless	885387.5mm
BD-08AB-D	24V	4A	80 L/min	7 bar		Brushless	1325387.5mm
BD-08VB-S	24V	4A	40 L/min		-85 kpa	Brushless	885387.5mm
BD-08VB-D	24V	4A	70 L/min		-85 kpa	Brushless	1325387.5mm
