BD-02A/BD-02V Brush Motor Micro Air Vacuum Pumps

Miniature diaphragm pumps use DC motor technology to drive a rubber diaphragm through an eccentric wheel.

Additional information

Voltage

3/6/12/24V DC

Air Flow

1L/min up to 3L/min

Liquid Flow

200-500ml/min

Pressure

1bar up to 1.5bar

Vacuum

-30kpa up to -65kpa

Motor

DC brush/DC brushless

Diaphragm

EPDM/FKM

Pump Construction Principle:

Miniature diaphragm pumps use the technology of a DC motor driving a rubber diaphragm through an eccentric wheel.

Pumps Features:

BD-02 series is a miniature diaphragm pump for air and vacuum, the most important feature is the small size and high flow rate. It is mainly used for inflating and suction. More features of the air pump are as follows.

  • Efficient and durable design
  • Smallest size and lightest weight
  • Oil-free and non-contaminating medium
  • Maintenance-free, easy to operate and install
  • Excellent air tightness



Model Composition:

We offer both brushed and brushless motors, with high quality DC brushless motors for 3000-5000 hours and brushed motors for 1000 hours.

With the optional brushless DC motor, we also offer a pulse width modulation (PWM) option. This unique feature is ideal for applications that require precise control of pump output.



Typical Parameter:

Model BD-02A air pump (positive pressure pump) and BD-02V vacuum pump (negative pressure pump) products, consisting of long-life brush motor and POM material pump body, the following parameters are common in the market and the most shipped parameters, we also support other parameters customization, welcome to consult.

Model: BD-02A typical parameter:

Parameter navigation

  • Air pump options:
  • Rated Voltage: 3v,6V,12V, 24V
  • Pressure:50kpa(0.5Bar)、100kPa(1Bar)、150kPa(1.5Bar)
  • Air flow:1L/min, 1.5L/min, 3L/min

Mini Air Pump Basic Specifications

▶ Model 1: BD-02A-1L

  • Name: Miniature diaphragm air pump
  • Rated Voltage: DC3V/6V/12V/24V
  • Power: 1.5W
  • Max pressure: ≥50kPa(0.5bar/0.05Mpa/7.25psi)
  • Air flow(@0bar): ≥1L/min
  • Noise:★

▶ Model 2: BD-02A-1.5L

  • Name: Miniature diaphragm air pump
  • Rated Voltage: DC3V/6V/12V/24V
  • Power: 2W
  • Max pressure: ≥100kPa(1bar/0.1Mpa/14.5psi)
  • Air flow(@0bar): ≥1.5L/min
  • Noise:★★

▶ Model 3: BD-03A-3L

  • Name: Miniature diaphragm air pump
  • Rated Voltage: DC3V/6V/12V/24V
  • Power: 2.5W
  • Max pressure : ≥150kPa(1.5bar/0.15Mpa/21.8psi)
  • Air flow(@0bar): ≥3L/min
  • Noise:★★★



Model: BD-03V typical parameter:

Parameter navigation

  • Vacuum pump options:
  • Rated Votage: DC3V/6V/12V/24V
  • Negative pressure(Vacuum): -30kpa(225mmHg), -50kpa(375mmHg), -65kpa(487.5mmHg)
  • Air flow:1L/min, 1.5L/min, 3L/min

Mini Vacuum Pump Basic Specifications

▶ Model 1: BD-02V-1L

● Name: Mini diaphragm vacuum pump
● Rated Voltage: DC3V/6V/12V/24V
● Power: 1.5W
● Negative pressure: ≥ -30kpa(225mmHg)
● Air flow: ≥1L/min
● Noise:★

▶ Model 2: BD-02V-1.5L

● Name: Mini diaphragm vacuum pump
● Rated Voltage: DC3V/6V/12V/24V
● Power: 2W
● Negative pressure: ≥-50kpa(375mmHg)
● Air flow: ≥1.5L/min
● Noise:★★

▶ Model 3: BD-02V-3L

● Name: Mini diaphragm vacuum pump
● Rated Voltage: DC3V/6V/12V/24V
● Power:2.5W
● Negative pressure: ≥-65kpa(487.5mmHg)
● Air flow: ≥3L/min
● Noise:★★★

General Specifications

  • Inlet&outlet dimensions: ID2.2mm. OD:4.0mm
  • Dimension: 55(L) x 24(W) x 40(H) mm
  • Weight: 71g
  • Material: Nylon
  • Valve: EPDM
  • Motor Type: DC Brush Motor
  • Power: 1-3W
  • Noise:50-65dB
  • Working type:  Continuous or Intermittent
  • Durable time: ≥500hours
  • Environment temperature range: 0~40℃
  •  Ambient humidity range: <80%



Application Scope:

BD-02 series of air pumps has an ultra-light weight of about 71 grams, flow rate up to 3LPM, pressure up to 1.5 bar, vacuum up to -65kpa, very wide range of applications, mainly in the medical, cosmetic, vacuum compression industry. Typical examples include.

  • Portable environmental gas analysis
  • Medical analysis
  • Negative pressure wound treatment device
  •  Breast pumps
  • Vacuum preserving machines
  • Nebulizer
  • Nasal Aspirators
  • Pressure and vacuum compression, etc.
