BD-07A-M/BD-07V-M oilless Small Piston Air Vacuum Pump Pneumatic Air Suction Pumps

small piston pumps through the cylinder in the fixed crank drive piston to achieve volume changes.

Additional information

Voltage

DC 12V/24V

Air Flow

15L/minup to 40L/min

Pressure

4.5 bar up to 6.5 bar

Vacuum

-80 kpa up to -85kpa

Motor

brush/brushless

Diaphragm

EPDM/FKM

Miniature Pump Construction Principle:

A small piston air vacuum pumps through the cylinder in the fixed crank drive piston to achieve volume changes, that is, the air in the pump cavity compression, and stretching, so as to form a large flow of vacuum (negative pressure) and positive pressure.

Small Piston Pumps Features:

BD-07 series is a miniature piston gas pump, air suction pump, oilless vacuum pump, micro pneumatic pump
the largest feature is the small size, low power, oil-free, low vibration, aluminum pump head, high-temperature resistant rubberand a variety of pressure and flow options, mainly for inflatable, booster, lift, Inhalation, suction, vacuum. More features of the air pump are as follows.

  • Efficient and durable design
  • Minimum size and lightest weight
  • High flow, high pressure, high vacuum
  • Aluminum pump head with high heat dissipation
  • Aluminum pump head, high temperature resistant
  • Oil-free and non-contaminating media
  • Maintenance-free, easy to operate, easy to install
  • Excellent air tightness



Model Composition:

The life span of these BD-07 series micro air pumps depends mainly on the type of motor used. We offer both brushed and brushless motors, up to 3000-5000 hours with premium DC brushless motors, and up to 800-1000 hours with  brush motors.

With optional brushless DC motors, we also offer Pulse Width Modulation (PWM) option. This unique feature is ideal for applications that require precise control of pump output.



Typical Parameter:

Model BD-07A-M positive pressure pump and BD-07V-M negative pressure pump products, consisting of long-life brush motor and PPS material pump body, the following parameters are common in the market and the most shipped parameters, we also support other parameters customization, welcome to consult.

Model: BD-07A-M typical parameter:

Parameter navigation

  • Air pump options:
  • Rated Voltage: 12V, 24V
  • Pressure:450kPa(4.5Bar), 500kPa(5Bar), 550kPa(5.5Bar), 600kpa(6Bar)
  • Air flow:15L/min, 20L/min, 25L/min, 35L/min

Miniature Air Pump Basic Specifications

▶ Model 1: BD-07A-M 15L

  • Name: Miniature piston air pump
  • Rated Voltage: DC12V/24V
  • Power: 24W
  • Max pressure: ≥450kPa(0.45Mpa/4.5bar/65psi)
  • Air flow(@0bar): ≥15L/min(15LPM/900L/H)
  • Noise:★

——————————

▶ Model 2: BD-07A-M 20L

  • Name: Miniature piston air pump
  • Rated Voltage: DC12V/24V
  • Power: 36W
  • Max pressure: ≥500kPa(0.5Mpa/5bar/72.5psi)
  • Air flow(@0bar): ≥20L/min(20LPM/1260L/H)
  • Noise:★★

——————————

▶ Model 3: BD-07A-M 25L

  • Name: Miniature piston air pump
  • Rated Voltage: DC12V/24V
  • Power: 36W
  • Max pressure :≥550kPa(0.55Mpa/5.5bar/80psi)
  • Air flow(@0bar):≥25L/min(25LPM/1500L/H)
  • Noise:★★★

——————————

▶ Model 4: BD-07A-M 35L

  • Name: Miniature piston air pump
  • Rated Voltage: DC12V/24V
  • Power: 48W
  • Max pressure :≥600kPa(0.6Mpa/6bar/87psi)
  • Airflow(@0bar):≥35L/min(35LPM/2100L/H)
  • Noise:★★★

——————————



Model: BD-07V typical parameter:

Parameter navigation

  • Vacuum pump options:
  • Rated Voltage: 12v, 24v
  • Negative pressure(Vacuum): -80kpa(600mmHg), -85kpa(637mmHg)
  • Air flow:17L/min, 25L/min, 30L/min

Mini Vacuum Pump Basic Specifications

▶ Model 1: BD-07V-M 17L

● Name: Mini piston vacuum pump
● Rated Voltage: DC12V/24V
● Power: 24W
● Negative pressure: ≥-80kPa(600mmHg)
● Air flow: ≥17L/min
● Noise:★

——————————

▶ Model 2: BD-07V-M 25L

● Name: Mini piston vacuum pump
● Rated Voltage: DC12V/24V
● Power: 36W
● Negative pressure: ≥-85kPa(637mmHg)
● Air flow: ≥25L/min
● Noise:★★

——————————

▶ Model 3: BD-07V-M 30L

● Name: Mini piston vacuum pump
● Rated Voltage: DC12V/24V
● Power:48W
● Negative pressure: ≥-85kPa(637mmHg)
● Air flow: ≥30L/min
● Noise:★★★

General Specifications

  • Inlet&outlet dimensions: ID4.0mm. OD:8.5mm
  • Dimension: 108 x 85.5x 43 mm(4.25 x 3.37 x 1.69 inch)
  • Weight: 600g
  • Material: Aluminium alloy pump head
  • Valve: High-temperature resistant rubber
  • Motor Type: DC Brush Motor
  • Rated Voltage: 12V/24V DC
  • Power: 24-48W
  • Noise:60-70dB
  • Working type:  Intermittent
  • Durable time: ≥1000hours
  • Environment temperature range: 0~45℃
  •  Ambient humidity range: <80%



Application Scope:

BD-07 series of air pumps has an ultra-light weight of about 600g, flow rate up to 40 LPM, pressure up to 6.5 bar, vacuum up to -85 kpa, a wide range of applications, mainly for health, beauty, industrial equipment. Typical examples include:

  • Electric tools
  • Lifting tools
  • Rehabilitation and physiotherapy together
  • Pressure and vacuum industrial instruments
  • Cosmetic suction instruments
