BD-07W 12V 24V Mini Diaphragm Water Pumps Water Purifier Pump Brush – BODENFLO

The BD-07W is a high-efficiency, versatile diaphragm pump designed for RO systems, beverage machines, and more, offering durability and reliable performance.

Additional information

Voltage

DC 12V/24V

Max Pressure

10bar

Air Flow

1.3L/min, 1.5L/min, 1L/min

Motor

brush/brushless

Diaphragm

EPDM/Corrosion Resistance

Structure Description: Micro Diaphragm Water/Liquid Pump:

The BD-07W micro diaphragm water pump is meticulously crafted for high-demand applications, including Water purifier, RO systems, Beverage equipment, Atomizers, . This pump is the cornerstone of innovation, designed to meet the rigorous standards of various industries with its robust and efficient performance.

The structure typically includes a motor, a diaphragm, inlet and outlet valves, and a pump housing. The motor powers the diaphragm’s movements to create pressure differentials, drawing water in through the inlet valve and pushing it out through the outlet valve. The housing contains and protects these components, ensuring the pump operates efficiently and reliably in purifying water by maintaining consistent pressure and flow rates. This configuration is designed to meet the demands of RO water purification systems, providing clean and safe water.

  • Pump Body Design: Specifically tailored for RO systems, ensuring optimal performance.
  • Flow Channels: Efficiently designed inlet and outlet channels for smooth flow.
  • Pressure Stabilization: Features a unique release channel with components for stable pressure.
  • Advanced Materials: Utilizes high-quality materials for longevity and reliability.



Key Features of 12V/24V BD-07W Brush Diaphragm Water Pump:

  1. Dry Running Capability: Safely operates without water, preventing diaphragm damage or leaks.
  2. Compact Design: Offers easy integration with a small footprint.
  3. Lightweight Construction: Ensures easy portability and installation.
  4. Energy Efficiency: Consumes low electrical current for efficient operation.
  5. Quiet Operation: Minimizes noise for a better user experience.
  6. Chemical Resistance: Customizable to resist strong acids and alkalis, enhancing durability.
  7. Optimized Space Efficiency: Maintains performance with sophisticated dynamic balance.
  8. High Performance: Delivers strong pressure and flow rates, surpassing industry standards.
  9. Long-term Reliability: Designed for continuous operation, ensuring an extended lifespan.

Diaphragm Water Pump Specifications of BD-07W:

Basic Specifications:

  • Model: BD-07W
  • Rated Voltage: 24 V DC
  • Rated Current: 0.5 A
  • Max Pressure: 10 Bar (145 psi)
  • Max Flow: 1 L/min
  • Working Pressure: 5 bar (72 psi)
  • Working Flow: 0.5 L/min

Motor Specifications:

  • Motor Type: DC Brush Motor
  • Noise Level: 55 dB
  • Durability: 1000 hours

Operational Environment:

  • Medium: General non-corrosive clean water; free of visible particles and fibrous materials; medium temperature between 3°C and 50°C.

Physical Dimensions:

  • Dimensions: 118.5 x 76 x 62.5 mm
  • Weight: 590g

Pump Materials

  • Pump Shell: POM
  • Diaphragm: EPDM (Customizable with corrosion resistance)

Additional Feature:

  • Customization: Can be customized with wires and terminals upon request.

Application Range of BD-07W DC Micro Water Pumps:

  • RO Water Purification Systems: Enhances efficiency and reliability in reverse osmosis water purification by providing stable pressure and flow.
  • Food and Beverage Machines: Ensures consistent pressure and flow in food and beverage processing equipment, contributing to quality control and production efficiency.
  • Atomizers: Ideal for use in atomizing devices, offering fine misting capabilities essential for humidification, cooling, and aroma diffusion applications.
  • Disinfection Equipment: Provides essential pressure and flow for disinfection machines, ensuring thorough and effective sanitization processes.
  • Beauty Devices: Supports beauty equipment with precise fluid handling for treatments such as microdermabrasion, hydration infusions, and other skincare applications.

Why Choose BODENFLO BD-07W

  • Innovative Design: Solves the issue of “dry running” without damaging the diaphragm or causing leaks, showcasing advanced engineering.
  • Efficiency and Durability: Provides high performance with low electrical consumption, minimal noise, and resistance to harsh chemicals, ensuring long-term reliability.
  • Versatility: Suitable for a wide range of applications, from RO systems to food and beverage processing, atomizers, disinfection equipment, and beauty devices, demonstrating its adaptability across industries.
  • Compact and Lightweight: Ideal for integration into various systems, enhancing portability and installation ease.
